For use in spot and general lighting.
Front glass
Genuine glass reflector
Aluminum heat sink
Material: die-cast aluminium
Surface: galvanized or powder coated
Colour rendering index Ra: 97
Colour distance (MacAdam): 3 SDCM
Life time: 50.000 h (L80 B10)
LED driver included: dimmable with trailing edge
weniger lesenCovering of the luminaire with thermally insulating material possible | no |
---|---|
CE-Conformity | yes |
RoHS | yes |
Protection class | II |
Degree of protection | IP40 |
Impact strength | IK00 |
Thermal insulation mark | yes |
Installation, electrical engineering expertise | yes |
Only for indoor use | yes |
Furniture installation, fire protection 'MM' | yes |
Installation note [flammable materials] | recessed luminaire suitable for direct mounting on normal flammable surfaces |
Installation in insulated ceilings, fire protection 'F with roof' | yes |
Ambient temperature [Ta [°C] | 0 - 25 |
---|
With light source | yes |
---|---|
Including LED driver | yes |
Light cone | Medium beam 21-40° |
---|---|
Colour temperature [K] | 3000 |
Total luminous flux [lm] | 670 |
Beam angle [°] | 38 |
Colour consistency (MacAdam) [SDCM] | 3 |
Colour rendering index Ra | 97 |
Colour rendering index R9 | 95 |
Fit for monitor workplace acc. EN 12464-1 | no |
Peak luminous intensity [cd] | 1100 |
Light distributor | reflector |
L80B10 - life time at 25 °C [h] | 50000 |
L70B50 - life time at 25°C [h] | 50000 |
Colour controllable (RGB) | no |
Colour temperature adjustable | no |
Light sharing | symmetric |
Light outlet | direct |
Lamp type | COB LED |
Suitable for number of lamps | 1 |
Diameter [mm] | 89 |
---|---|
Height [mm] | 65 |
Weight [g] | 470 |
Operation by Bluetooth | no |
---|---|
Adjustability | Swivelling |
Mounting method | surface mounted |
Suitable for general lighting | yes |
Suitable for recessed wall installation | no |
Suitable for wall mounting | no |
Compatible with Apple HomeKit | no |
Compatible with Google Assistant | no |
Compatible with Amazon Alexa | no |
IFTTT support available | no |
Adjustable [°] | 20 |
Kind of disposal at the end of the life time | specific collection points, please consider the local regulations |
Reflector | high gloss |
Suitable for lighting accessories | no |
Reflector colour | silver |
---|---|
Material housing | die-cast aluminium |
Colour housing | chrome |
Material cover | glass |
Heat sink | yes |
Material of Heat sink | aluminium |
Material of reflector | glass |
Front glass | yes |
Colour | chrome |
Type of LED driver | LED driver |
---|---|
Lamp power [W] | 8 |
Max. system power [W] | 9,5 |
Rated voltage of the LED driver [AC [V] | 220 - 240 |
Input frequency [Hz] | 50 - 60 |
Lamp holder | without |
Wire cross section | 15 cm with Mini AMP plug system 2-pole |
Exchangeable LED driver | yes |
Dimmable | yes |
Type of dimming | trailing edge |
Through-wiring possible | no |
Electrical connection with connector system | yes |
