Presence detector BT for LED High Bay F400-SI

Presence detector with Bluetooth
SKU: 1740012011
EAN: 4044538074115
Article Choice

Bluetooth presence detector for Smartmatic 2.0 App

Makes the F400-SI LED high bay luminaire a smart luminaire

weniger lesen
mehr lesen

Downloads
MontageanleitungMontageanleitung
Ausschreibungstext neutralAusschreibungstext neutral
Ausschreibungstext nobiléAusschreibungstext nobilé
ProduktdatenblattProduktdatenblatt

Technical Data

  • Product contents
    Accessory yes
    Spare part no
  • Temperature specifications
    Ambient temperature [Ta] [°C] -20 - 50
  • Dimensions and weight
    Diameter [mm] 55
    Height [mm] 42
    Weight [g] 21
    Mounting height max. [m] 12
  • Protection specifications
    CE-Conformity yes
    RoHS yes
    EMC Standard EN 55015; EN 61000-3-2; EN 61000-3-3; EN61547
    RED Standard ETSI EN 300 440 V2.1.1; ETSI EN 301 489-1 V2.2.3; ETSI EN 301 489-3 V2.1.1; EN 60598-1; EN 60598-2-1; EN 62493; EN 62479
    Degree of protection IP65
    Installation, electrical engineering expertise yes
  • Other specifications
    Type of accessory/spare part Presence detector
    Compatible with Apple HomeKit no
    Compatible with Google Assistant no
    Compatible with Amazon Alexa no
    IFTTT support available no
    Kind of disposal at the end of the life time specific collection points, please consider the local regulations
    APP Smartmatic 2.0
  • Material and colour
    Material PMMA
    Colour multi-coloured
  • Technical lighting specifications
    Detection angle [°] 360
  • Electrical specifications
    Frequency band 2.4GHz
    Sink current [dimming] [mA] 25
    Rated current max. [A] 0,05
    Detection range [m] 3,6 - 16
    Rated voltage (DC) [V] 12 - 24
    Control system Smartmatic
    Transmission protocol BLE 5.0 (Mesh)
    Transmission power [dBm] 100
    Bluetooth WiFi radio range outdoor [m] 12
Back to: High Bay luminaires
