N 5020 CSP LED chrom 3W 3000K
LED Möbeleinbauleuchte, CSP LED
SKU:
1850209402
EAN: 4044538058689
EAN: 4044538058689
Flache Möbeleinbauleuchte mit geringer Einbautiefe.
Material: Stahl/Polycarbonat/Glas satiniert
Oberfläche: lackiert oder galvanisiert
Farbwiedergabeindex Ra: 90
Farbabstand (MacAdam): 3 SDCM
Lebensdauer: 50.000 h (L80 B10)
Betriebsgerätempfehlung: EL-350mA CC Serie
weniger lesen
Technical Data
-
Temperature specifications
Ambient temperature [Ta [°C] 0 - 25 - Protection specifications
Covering of the luminaire with thermally insulating material possible no CE-Conformity yes RoHS yes Protection class III Degree of protection IP20 Impact strength IK00 Thermal insulation mark yes Installation, electrical engineering expertise yes Only for indoor use yes Furniture installation, fire protection 'MM' yes Installation note [flammable materials] recessed luminaire suitable for direct mounting on normal flammable surfaces Installation in insulated ceilings, fire protection 'F with roof' no Note ensure constant convection and do not cover by insulation material - Product contents
With light source yes Including LED driver no - Technical lighting specifications
Light cone Extreme wide beam >80° Colour temperature [K] 3000 Colour of light warm white LED efficiency [lm/W] 50 Total luminous flux [lm] 200 Beam angle [°] 85 Colour consistency (MacAdam) [SDCM] 3 Colour rendering index Ra 90 Colour rendering index R9 60 Fit for monitor workplace acc. EN 12464-1 no Peak luminous intensity [cd] 120 Light distributor Diffuser L80B10 - life time at 25 °C [h] 50000 L70B50 - life time at 25°C [h] 50000 Colour controllable (RGB) no Constant light output (CLO) no Light source replaceable no Light sharing symmetric Light outlet indirect Lamp type CSP LED Suitable for number of lamps 1 - Dimensions and weight
Length [mm] 66 Width [mm] 66 Diameter [mm] 66 Height [mm] 18 Weight [g] 46 Ceiling cut-out [diameter] [mm] 58 Built-in depth [mm] 18 - Material and colour
Reflector colour silver Front glass glass satined Material steel/polycarbonate/glass satined Colour chrome Surface finishing galvanized - Other specifications
Adjustability Not adjustable Operation by Bluetooth no Mounting method recessed-mounted Suitable for general lighting yes Suitable for recessed wall installation no Suitable for wall mounting no Kind of disposal at the end of the life time specific collection points, please consider the local regulations Reflector Aluminum reflector Suitable for lighting accessories no - Electrical specifications
Type of LED driver LED driver Lamp power [W] 3 Nominal current of luminaire [mA] 350 Constant current [mA] 350 Lamp holder without Type of wiring Ending Exchangeable LED driver yes Dimmable yes Type of dimming Led driver dependent Length of cable [cm] 30 Through-wiring possible no Rated voltage max. [V] 8,6 Electrical connection with connector system yes Type of connection [luminaire] AMP plug-system 2-pole
