COB LED Module N5800 7W warmwhite 38°
SKU:
8058001238EAN: 4044538049878
Ideal for conversion of the N 5800 spot to the energy-saving and long-lasting LED technology
Genuine glass reflector
Colour rendering index Ra: 90
Colour distance (MacAdam): 3 SDCM
Life time: 50.000 h (L80 B10)
LED driver included: dimmable with trailing edge
Terminal block and through-wiring (L, N, PE)
Ensure constant convection and do not cover by insulation material.
Material: aluminium/glass
Dimensions (ØxH): 50x47 mm; Dimensions LED driver (ØxH): 57x19 mm
Connection: 15 cm with AMP plug system 2-pole
Farbwiedergabeindex Ra 90
Farbabstand (MacAdam): 3 SDCM
Lebensdauer: 50.000 h (L80 B10)
Betriebsgerät: inklusive
Dimmung: mit Phasenabschnittsdimmer
Material: Aluminium/Glas
Abmessungen (ØxH): 50x47 mm; Abmessungen LED Betriebsgerät (ØxH): 57x19 mm
Anschlussleitung: 15 cm mit AMP-Stecksystem 2-polig
weniger lesen
Technical Data
-
Energy consumption labeling
Energy efficiency class E Part number of the light source 8058001239 EPREL-Registration number 977415 - Protection specifications
CE-Conformity yes Protection class II Degree of protection IP20 Installation, electrical engineering expertise yes Only for indoor use yes Furniture installation, fire protection 'MM' yes Mercury-free yes Note ensure constant convection and do not cover by insulation material - Temperature specifications
Ambient temperature [Ta [°C] -20 - 40 Case temperature [Tc] [°C] 60 - Product contents
Including LED driver yes - Technical lighting specifications
Non-directional (NDLS) or directional [DLS] DLS Colour temperature [K] 3000 Colour of light warm white LED efficiency [lm/W] 118 Total luminous flux [lm] 790 Useful luminous flux (Φuse) [lm] 760 Useful luminous flux (Φuse) related to Narrow cone (90°) Beam angle [°] 38 Colour consistency (MacAdam) [SDCM] 3 Colour rendering index Ra 90 Colour rendering index R9 70 Chromaticity coordinates (x) 0,43 Chromaticity coordinates (y) 0,403 Peak luminous intensity [cd] 1250 L80B10 - life time at 25 °C [h] 50000 L70B50 - life time at 25°C [h] 50000 Rated lifetime factor 0,9 Lumen maintenance factor 0,96 Lighting Technology used LED Anti-glare shield no Envelope no envelope Colour-tuneable light source no Light source replaceable no High luminance light source no Number of LEDs 1 Lamp type COB LED - Dimensions and weight
Diameter [mm] 50 Height [mm] 47 Weight [g] 70 Difference to standard dimensions yes - Material and colour
Material aluminium/glass Colour matt chrome - Other specifications
Suitable for general lighting yes Compatible with Apple HomeKit no Compatible with Google Assistant no Compatible with Amazon Alexa no IFTTT support available no Kind of disposal at the end of the life time specific collection points, please consider the local regulations Shape round Appropriate disposal acc. to WEEE yes - Electrical specifications
Min. number of switching cycles 12500 Type of LED driver LED driver Energy consumption during operation [kWh/1000 h] 7 Lamp power [W] 7 Connected Light Source (CLS) no Nominal current of luminaire [mA] 200 Voltage type AC Lamp holder other Wire cross section Mini AMP plug (male) Connection type primary 15 cm with Mini AMP plug system 2-pole Dimmable yes Type of dimming trailing edge Suitable for constant voltage no Suitable for constant current yes Operating voltage [V] 220 Warm up time to 60% nom. Lumen < [s] 1 Through-wiring possible yes Lamp voltage [V] 35 Rated voltage of LED driver [V] 220 - 240 Forward voltage drop (DC) [V] 35 External driver required yes
